Semi-Automatic Soldering Machine Feeder Equipment (Produced With DFM, PDF) - SolidWorks - Free Download

Soldering Machine Semi-Automatic Loading Machine Action Process:
1. The product is manually loaded into the fixture of the equipment for positioning;
2. The left working solder feeding device operates, using a rotary cylinder equipped with a U-shaped slot to complete the PPU cycle loading action;
3. The right solder feeding device works together, utilizing the traditional cylinder and linear guide method, with the Z-axis using a platform-changing cylinder to complete the solder feeding action.
