This model is an end-effector claw for a robot, featuring a dual-station independent design. The telescopic mechanism uses a 1210 ball screw drive mechanism, powered by a Panasonic servo motor with a timing belt transmission system. The rotation mechanism is based on the SLT016 ball spline structure, with a hollow spline shaft to facilitate wiring through the magnetic claw. The rotation limiting mechanism employs a gear system to control the rotation angle within a 380° range. The file package includes formats such as STEP, IGS, X_T, and EASM.
