Roll Forming Machine Equipment (steel Industry)

Roll Forming Machine Equipment, specifically a SW12 roller track forming machine used in the steel industry. Original format files are available for sharing, as well as a universal XT format.

The roll forming machine is composed of a roll head device, roll head translation device, transmission and braking device, machine base, spindle assembly, die holder elliptical motion device, roll head holder, motor, and electrical control system. The mechanical structure design is relatively complex, but this model is drawn very clearly. Welcome to download.
