Mixed-Flow Pump Turbine

Mixed-Flow Water Pump Turbine SW2014 Design

Provides SolidWorks source files + X_T universal documents. Welcome to download.

The water flow enters the runner radially and then exits the pump primarily in an axial direction. The runner’s shape is similar to that of a pump and is generally suitable for water heads of 100 to 600 meters. For water heads exceeding 600 meters, two or more runners are usually connected in series to form a multi-stage setup. Japan has tested a single-stage runner for 800-meter head conditions, which is expected to enhance the applicable head range for single-stage runners. The mixed-flow water pump turbine has a simple structure and a wide range of suitable water heads, making it the most widely used model.
