Instant Print and Apply Automatic Labeling Machine (mature)

Conveyor Line Print and Apply Automatic Labeling Machine (is the equipment for applying rolled self-adhesive paper labels (paper or metal foil) onto PCBs, products, or specified packaging. Labeling machines are an indispensable part of modern packaging. The A1000 I designed can be used in conjunction with barcode printers A2+, A4+, and A6+, targeting semi-automatic labeling and automated production lines. It can provide you with cost-effective and stable solutions and production efficiency.

A. Long Operational Lifespan: The transmission cylinder device uses ball bearings, resulting in low wear.
B. Accommodates Different Labeling Heights: Adjustable pneumatic cylinder for labeling products of various heights. The factory-equipped pneumatic cylinders also come in different height options.
C. Pre-Peel Test Button: Used for labeling test functionality. When the button is pressed for the first time, the first label is printed out and positioned at the stripper; pressing the button again allows the label to be applied to the product.
D. Pressure Gauge: The pressure gauge can be installed on the labeling machine or a stand. The micro filter can filter out air impurities, and the pressure gauge can control the stable air pressure flow needed to ensure labeling quality.
E. High Reliability: The supporting airflow, adsorption airflow, and lift speed of the pneumatic cylinder are all adjustable. For fragile products and packaging, the output force can be adjusted to less than 10N (1kg). To avoid contamination in the suction pipeline, an air pressure pulse cleans it after each labeling operation.
F. Label Size: Suitable for labels with a width of 25 – 176 mm and a length of 25 – 200 mm.
G. Supporting Airflow: Supporting airflow helps to fix the label onto the pad.
H. Digital I/O Interface: Sensors or manual switches on the PLC can initiate the labeling process.
