Horizontal Lathe Ca6140 Complete Design Drawings

CA6140 Lathe Overall Design 3D Assembly Model Full Set of Drawings The entire UG 3D assembly model contains more than 500 parts, including: spindle box, slide box, feed box, tool holder and carriage, tailstock, and lathe bed, among six parts. The assembly of each component is also included in the entire compressed package, which can be searched by file name as needed. (If the model cannot be displayed, please select assembly loading items from the folder) CA6140 type horizontal lathe is a universal machine tool of ordinary precision level. Its special function is turning various threads within a certain range, including the function of cutting metric threads, inch threads, module threads, and pitch diameter threads. The speed change mechanism of the feed drive chain can strictly and accurately change according to the standard pitch sequence. The CA6140 type horizontal lathe feed box is fixed at the left front of the bed, containing feed motion conversion devices and control mechanisms.
