General Fixture Module Press-Fit Frame (including Bom)

This equipment is mainly used for the assembly process of secondary bending of products in electronic device processing equipment. It is a desktop semi-automatic jig that, after fixing the product with the Y-axis fixture, pushes the product into the cutting station using a cylinder. The Z-axis uses a dual-rod cylinder to complete the cutting. The project files include 3D drawings in XT universal format, and mechanical designers are welcome to download, study, and communicate for project learning.
