Fully Automatic Smd Taping, Testing and Packaging Machine

A fully automatic SMD taping test packaging machine 3D model
Designed using Solidworks 2012, it includes sldasm and sldprt source files and CAD dwg drawings. This equipment is a taping packaging machine in the semiconductor industry.
It uses a 45-degree gravity slide method to allow products to flow out of the tube on their own. To prevent jamming, there is an added air-blowing function.
The taping and packaging process is completed by a 45-degree pick-and-place robot. This robot has a very fast pick-and-place speed. In the middle, you can see a CCD vision camera detection mechanism.
This SMD taping packaging machine equipment includes: packaging machine assembly diagram, frame diagram, carrier tape assembly, feeding assembly, tape collecting assembly, sealing assembly, picking assembly, control box, and other components.
Its structure is reasonable, and the model is complete. Welcome to download, highly recommended.
