A 3D model of an automatic foil laminator, also known as a surface laminating machine. SW design sldasm and sldprt source files are provided. The laminator structure includes: 08-00 base paper feeder, 02-00 main drive of the feeder, 01-00 pre-code paper mechanism, 03-00 main paper feed frame, 07-00 rear paper delivery for surface paper, 06-00 front paper delivery for surface paper, 10-00 gluing section, 11-00 pressing section, 05-00 frame wall section, 12-00 main machine wall section, 09-00 main drive section, 04-00 feeder head adjustment section, and general assembly, etc.
The fully automatic laminator combines two different types of paper. The laminator structure is equipped with two feeders arranged in parallel. A central positioning mechanism is installed on the laminator mechanism, dividing the laminator mechanism into two paper paths. Wing-shaped spring pieces are set on both sides of the laminator mechanism. The main structures include the gluing section, pressing section, and paper collection section, which contains partial engineering drawings. Download and learn it.
