This equipment mechanism is designed with SW2016 and includes part features. It features non-standard automation custom design, with drawings already used in actual production, showcasing many classic structures. The presented 3D model includes mostly complete independent robotic arm mechanisms for material handling. The linear motion modules involved, and the servo/stepper motor selection parameters, align with actual calculation requirements. The control system employs a PC-based C++/C# paired with CCD vision recognition or a PLC for multi-axis point, single-action control. Linear slide selection primarily uses Hiwin/THK, cylinder selection is AIRTAC/Festo, and sensor selection is mainly Keyence/JiaJun/Omron. The overall structure is clear, parts are complete, and design is reasonable, making it an ideal reference or learning material for your design. Please note that the model dimensions provided should not be used for manufacturing! The complete extraction includes STP and UG commonly editable formats.
