Disinfection Device Face Cover (Hot Runner) - UG(NX) - Free Download

The model is an injection mold diagram for the face cover of a sterilizer; the material is semi-transparent PC, one cavity two pieces; uses a valve gate hot runner system for injection, and the mold base is a non-standard custom model; the front mold is designed with multiple ejector blocks to prevent the product from sticking to the front mold; the rear mold is designed with angled ejectors and ejector pins for demolding; everyone is welcome to download and learn.
