Complete 3D Model Of Cabinet Hanger Assembly Machine + BOM List

Sold by

MrBlue

@ MrBlue

[mecworks-btn]

SKU: A012501001961 Category: 3D Projects Tags: Assembling Machine, Assembly Machine, Automation Equipment, Cabinet, Capping Machine, Discharge Mechanism, Feeding Mechanism, Hanging Code, Non-Standard Equipment, Turntable Mechanism, VIP Project

Description
Additional information
Reviews (0)
More Products

Automatic Cabinet Hanging Code Assembly Machine Includes 3D Model + Engineering Drawings + STP Files + Standard Parts List + Machining Parts List
The equipment structure includes an R-piece feeding mechanism, swing arm feeding mechanism, discharge mechanism, electrical control, hook feeding mechanism, frame mechanism, screw feeding mechanism, upper cover feeding mechanism, capping mechanism, turntable mechanism, etc. The design is detailed and has high reference value!

Specification: Complete 3D Model Of Cabinet Hanger Assembly Machine + BOM List

Design Software	SolidWorks
Editable	Editable, With parameters
File Formats	dwg, Sldasm, SLDDRW, Sldprt, step(stp)
Industry Application	Mechanical Equipment
Sharing Level	Diamond
Version	2016
