Automatic Aluminum-Plastic Film Punching Shell Machine and Forming Machine SW Design 3D Model, sldasm, sldprt documents. Purpose: Mainly used for aluminum-plastic film forming of polymer lithium-ion cells. Automatic feeding, cutting. Power: 600 pieces/hour, primarily determined by the size of the battery. Non-standard equipment for aluminum-plastic film punching shell, the structure mode includes automatic feeding from the material roll, stepping feed, stretch forming, and fixed-length cutting. It continuously forms and cuts the coil into individual pieces, realizing automated production. It utilizes the principle of gas-liquid boosting to achieve the pressure required for punching, converting smaller air source pressure into larger hydraulic output, thus driving the mold to form the aluminum-plastic film punching shell. The machine is very mature with feeding, forming, positioning, and shearing. It can be used for learning purposes and comes with SolidWorks original file, containing editable parameters.
