Activated Carbon + Uv Photodegradation Integrated Equipment

This VOC waste gas treatment device uses activated carbon adsorption + UV photolysis + photocatalyst. The adsorption air volume is 2000m³/h. The drawing design is independently designed and uses SolidWorks2014 as the drawing software. The complete set of drawings includes all details and can be edited, not just the usual slprt format viewing drawings. I am engaged in the environmental engineering profession and am proficient in various waste gas treatment processes. This drawing is provided for peer communication and should not be disseminated.
